Trick Flow PowerOval 280cc Cylinder Heads for Big Block Chevrolet 1.640" dual valve springs, Titanium Retainers - TFS-4131T003-M13

Trick Flow PowerOval 280cc Cylinder Heads for Big Block Chevrolet 1.640" dual valve springs, Titanium Retainers - TFS-4131T003-M13

SKU: TFS-4131T003-M13 Categories: , Tags: , , , , ,

** Stock & Price available upon request, please contact our office for all enquiries **

Trick Flow PowerOval 280cc Cylinder Heads for Big Block Chevrolet 1.640″ dual valve springs, Titanium Retainers – TFS-4131T003-M13

Description

Trick Flow PowerOval® 280 cylinder heads for big block Chevy are an ideal upgrade from factory cast iron heads for street/strip and marine applications. They feature an oval intake port design that produces excellent low and midrange torque and horsepower, plus more efficient heart-shaped, CNC-profiled combustion chambers, .300″ raised exhaust ports, extra-thick decks and walls for porting, and Fast As Cast® runners for near- CNC-ported performance at standard cast head prices. CNC bowl blended valve seat transitions promote high velocity and huge airflow volume and 24 degree valve angles with 4 degree side cants further increase airflow.

UPC: 842645109287
Combustion Chamber Volume (cc): 113
Intake Runner Volume (cc): 280cc
Exhaust Runner Volume (cc): 129cc
Cylinder Head Style: Assembled
Cylinder Head Material: Aluminum
Intake Port Shape: Oval
Intake Valve Diameter (in): 2.190 in.
Cylinder Head Finish: Natural
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: No
CNC-Machined Exhaust Runner: No
Combustion Chamber Style: Heart
Intake Port Location: Standard
Exhaust Port Shape: D-port
Exhaust Port Location: Raised
Spark Plug Style: Angle
Intake Valves Included: Yes
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.880 in.
Valve Springs Included: Yes
Maximum Valve Lift (in): 0.850 in.
Outside Diameter of Outer Spring (in): 1.640 in.
Damper Spring Included: Yes
Number of Springs Per Valve: Dual
Retainers Included: Yes
Retainer Material: Titanium
Locks Included: Yes
Lock Style: 10 degree
Valve Stem Seals Included: Yes
Valve Stem Seal Style: Positive stop
Rocker Arm Studs Included: Yes
Rocker Arm Nut Thread Size:
7/16-20 in.
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: Yes
Guideplate Pushrod Size: 3/8 in.
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 24/4
Exhaust Valve Angle: 15/4
Valve Guides Included: Yes
Valve Guide Material: Bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Quantity: Sold individually
Notes: Exhaust port is raised 0.300 in. over stock.
